Untergegensonnenbogen (EE63)

Description

Light Path
EE63 - Subparhelic Arc
Crystal Type:
  • Column Crystals
Orientation:
  • double oriented
Light Path:
  • Refraction on two side surfaces and reflection on base surface
Occurrence:
  • very rare
The subanthelic arc resembles the heliac arc in appearance. However, it lies in the region of the anthelion. It is colorless and crosses the subanthelion (EE30), which lies at the antisolar point below the horizon. The loops of the heliac arc and the subanthelic arc touch at the sun's meridian in the vicinity of the zenith. Previous observations have been made in Antarctica, from Finnish lamp-ice fog experiments, as well as from the Neklid phenomenon.

Simulation

Betätige den Slider, um die Sonnenhöhe zu ändern.

Origin

The subparhelic circle is created by internal reflections in Parry-oriented column crystals, with several possibilities involving different numbers of total internal reflections in the crystal.

Photos

Subparhelic Bow
Bright subparhelic bow observed on 30.01.2014 in the Neklid ski area, CZ (Photo: Claudia Hinz)
Lower Antisolar Arc
Bright lower antisolar arc in ice fog. Observed on 30/01/2014 in Neklid, CZ (Photo: Wolfgang Hinz)
